Wifi Smart Home Control Panel Smart Switch Electronic Lock Tuya Control Panel Music Light Tuya Series Home Appliance Controller
This product is our latest new product on the market. The UI interface currently supports Chinese and English . Voice wake-up currently only supports Chinese.
The data package of various languages is being upgraded and developed. It can be operated normally on the mobile phone or on the panel. Other functions are normal!!!
● Android 8.1 System
● RAM: 1G
● ROM: 8G
● Language: only English and Chinese
● Custom APP Installation
● 2-channel Speaker Output
● Watch online music, videos, radio and other programs
● Multi-stage timing switch, music play,linkage control of smart home
● Support external 485 control local machine
● Support TF card, OTGUSB disk, local play and read
● Remote control operation
● Support departure doorbell
● Support play music, stories, children's songs, tell jokes, check weather, check flights, smart home control
● Bluetooth playback, the host can control the Bluetooth playback device to switch music
● Support trigger doorbell function
● Support linkage trigger to play music
● Support linkage trigger shutdown
● Support timing output level signal linkage with other equipment
● Support external equipment to control the machine through 485
● Time switch machine, self - set timing boot songs
● Support external RJ45
● Support TUYA, TikTok, Spotify, BluetoothPlay, Smart Youtube, Go Keyboard, Pandora, etc.
WiFi audio Wall panel Amplifier Products Instruction Details:
1. Speaker: speaker cable (200 cores), RVH2X100, RVH2X200 connected to SPK R+ and SPK R-.
2. Audio output: audio cable (three-core shielded cable: commonly known as microphone cable),
RVVP2X0.5, RVVP2X0.75, connect to OUT R + OUT L + GND, can be connected to other amplifier.
3. Audio input: audio cable (three-core shielded line: commonly known as microphone line),
RVVP2X0.5, RVVP2X0.75, connect AUX L + AUX R + GND.
4. Trigger doorbell: Connect GND + DB to trigger the doorbell.
5. Trigger on/off: connect GND + ON to trigger on/off.
6. RS485 interface (optional): 485 cable, connected to 485A + 485B.
7. USB: External OTG USB, can read U disk with adapter.
8. TF card: Read TF card interface.
9. Power switch: long press for 2 seconds to turn on, long press for 2 seconds to turn off,
short press for lock screen / unlock.
10. Volume down key
11. Volume up key
13. Power supply terminal: Connect AC110V-240V power supply.
Reminder: If the speaker exceeds 25W, it needs to be used with an amplifier.
6.8-inch Smart Touch Control Panel
