New 4.3 Inch Video Doorbell Wireless Peephole Security Doorbell 720P Video Visual Intercom Night-Vision Pir Smart Wifi Doorbell
Regular price $66.21 Sale price
Tax included. Shipping calculated at checkout.
1.4.3 inch high-definition LCD screen, metal outdoor camera, anti-dismantling design;
2.160 degree HD wide angle;
3. Intelligent motion detection and recognition, automatic recording and recording;
4. Night vision function, you can see clearly at night;
5.2 million pixels, high-definition photo quality;
6.Maximum support 32G card, intelligent identification, automatic cycle coverage according to time;
7. Power off memory function, changing the battery does not affect the personality settings;
8 chord music to choose from
A. Indoor unit size: 135*76*15.5MM
B. Outdoor unit size: 62*62*15MM
C. Door hole range: 15-55MM
D. The thickness range of the door: 35-105MM
E. LCD screen size: 4.3"
F. Camera pixel: 200W
G. Lithium battery: 1500MAH 3.7-4.2V
H. Picture and video specifications: 720P
Remove the cat-eye head of the traditional optical sight glass, the recommended door hole is between 15mm ~ 55mm
Insert the screw that is selected to suit the door thickness and screw it into the cat's eye head screw hole. Do not tighten it. If the door thickness is greater than 95mm, a longer screw is especially needed.
Tear off the adhesive tape on the cat's eye head shell, please note that the doorbell button is down, let the flat cable (FPC) and the screw rod fixed on the cat's eye head pass through the door hole together, and then adjust the up, down, left, and right positions of the cat's eye head to glue On the door, please note that the cable connector should be downward.
Let the flexible flat cable (FPC) pass through the middle hole of the bracket, insert the screw from the left side of the large hole in the upper hole of the bracket, and slide the bracket to the left to align the center of the flexible flat cable (FPC).
Tighten the screws to fix the bracket and straighten out the FPC.
Take off the cable (FPC) cover, insert and fasten the cable in the direction indicated by the arrow, connect the flexible cable (FPC) and then cover the cable (FPC) cover.
Turn the indoor unit back, straighten the flexible cable (FPC), align it with the bracket port of the device, and slide it down vertically.
Make sure that the device is firmly fixed to the door.
Open the battery cover to load the battery, insert the SD card, and power on to test whether each function is working properly.
