Anjielosmart New 3.5 Inch Wireless Digital Baby Monitor Camera Nanny Security Night Vision Temperature Monitor
Parameters:
a.Functions
|
Features |
Descriptions |
|
Frame rate |
15-25 Rate |
|
Signal strength indicator |
4 levels |
|
Volume control |
10levels |
|
Intercom |
Two ways |
|
Voice control |
There is a sound that automatically turns on the screen, and the receiver has an alarm tone. |
|
One receiver Muti- transmitter |
Can receive one transmitter with four transmitters, can switch display |
|
LCD Size |
3.5" 320*240 RGB color LCD |
|
Transmission security |
Need to be pair coding |
b: Parameters
|
LCD receiving voltage |
DC：5V/1000MA；Battery：built-in 3.6V/1300MAH Li-Battery |
|
Transmission frequency |
2.4GHz ISM Band |
|
Wireless working mode |
FHSS |
|
Transmission power |
19dBm@CW mode |
|
Transmission rate |
3Mbps |
|
Transmission distance |
200-300 meter in open area |
|
Working current |
TX：400mA MAX，RX：500mA MAX，standby: 200MA |
|
Charging current |
120-280MA |
|
Audio sampling rate |
16K |
|
Audio frequency response range |
120Hz~3KHz |
|
Voice control level |
35--50dB@ MIC Input |
|
Camera resolution |
0.3 Mega pixels |
|
Image Resolution |
320*240QVGA |
|
Video transmission rate |
15-25FPS |
|
Total harmonic distortion |
<5.0% |
|
Signal to noise ratio |
46dB |
|
Receiving sensitivity |
-96dBm@BER=1e-3 |
|
Night vision distance |
2—3 meter |
|
Humidity range |
20--80% RH |
|
Temperature range |
0℃--45℃ |
Package Contents:
● 2* 5V DC mirco USB interface power supply
● 1* 2.4G Wireless LCD Baby Receiver
● 1*2.4G wireless camera
● 1*User's Guide
